ICQ Fans
Perfect for medium to high volume and pressure applications
High reliability TEFC or ERM motors with sealed for life bearings
Class ‘H’ available across all sizes
EXE, EXD, motors available across the range
High performance backward curve centrifugal impellers
Fully speed controllable
Flexibility
Fans can be mounted at any angle
Durable
Motor enclosure feature minimum IP54 protection as standard with higher ratings are available on request.
The ICQ series is a range of inline duct mounted fans for use in general ventilation systems.
All models are built around high-performance centrifugal impellers driven by totally enclosed fan cooled (TEFC) or external rotor motors (ERM).
Note that single phase ICQ series fans are only available in ERM models.
Find the right ICQ fan for your project
Use our online selection tool to help you select the best ICQ fan for your project.
And best of all – you can download all data and documentation before you place your order.
